Simple ESP32 Projects for Battery-Powered Devices

If you're starting out with the ESP32 and want to build something that runs on batteries, you're in the right place. The ESP32 is a powerful chip, but it can also be a bit of a power hog if you're not careful. The trick is to make it sleep most of the time and only wake up when it has a job to do. Let's look at some straightforward project ideas and how to make them last on a single charge.

How to Make Your ESP32 Sip Power, Not Guzzle It

Think of your ESP32 like a person. If it's running around all the time (active mode), it gets tired and hungry (drains the battery) fast. But if it takes long naps (deep sleep), it uses almost no energy. Your goal is to keep it napping as much as possible.

Key Things to Remember

• Put it to deep sleep: This is your number one tool. The chip shuts down almost everything and uses just a tiny bit of power to keep time or wait for a wake-up signal.
• Be smart with sensors: Don't check a temperature sensor every second if you only need a reading every hour. Turn the sensor on, take a reading, then turn it off.
• Write efficient code: Avoid using `delay()` in your main loop. It keeps the processor busy doing nothing. Use timers or non-blocking code instead.
• Choose the right way to talk: When sending data, protocols like MQTT are great because they are lightweight and your ESP32 can send a message and go back to sleep quickly.

Project Ideas You Can Try

Here are a few practical projects that are perfect for battery power:

1. Wireless Temperature/Humidity Logger: Place a sensor in a room, greenhouse, or even a fridge. It wakes up every 30 minutes, reads the data, sends it to a server (like Home Assistant or ThingSpeak), and goes back to sleep. A small battery can power this for months.
2. Smart Plant Watering Monitor: Use a soil moisture sensor. The ESP32 checks the soil once a day. If it's too dry, it can send you a notification or even trigger a water pump (though the pump itself would need a separate power source).
3. DIY Smart Button: A simple button that, when pressed, wakes the ESP32 from deep sleep. It then sends a command over Wi-Fi to turn on a light, play music, or order pizza, before going back to sleep instantly.

A Basic Code Structure to Get You Started

Almost all battery-powered projects follow this same pattern. Here’s a skeleton code to show you how it works:

#include
#include  // For MQTT

// Your Wi-Fi and MQTT details
const char* ssid = "your_SSID";
const char* password = "your_PASSWORD";

void setup() {
  Serial.begin(115200);

  // 1. Connect to Wi-Fi (this uses a lot of power, so be quick!)
  connectToWiFi();

  // 2. Do your main task (read sensor, send data)
  readSensorAndPublish();

  // 3. Prepare for deep sleep
  Serial.println("Going to deep sleep for 60 seconds");
  // Use the ESP32's internal timer to wake up after 60 seconds
  esp_sleep_enable_timer_wakeup(60 * 1000000); // microseconds

  // 4. Enter deep sleep
  esp_deep_sleep_start();
}

void loop() {
  // This will never run! The chip resets after deep sleep.
}

void connectToWiFi() {
  // Your Wi-Fi connection code here
}

void readSensorAndPublish() {
  // Your sensor reading and MQTT code here
}

Notice that the `loop()` function is empty? That's because after `esp_deep_sleep_start()`, the ESP32 completely shuts down. When the timer wakes it up, it restarts from the beginning of the `setup()` function. This restart is normal and key to saving power.
